Inconel Alloy Fittings Supplier & Stockist in India
Inconel Alloy 600/601/625/718 Buttweld & Forged Fittings Exporter
ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 Inconel Alloy N06600/N06601/N06625/N07718 Threaded & Socketweld Fittings Manufacturer & Trader
Prithvi Steel & Engineering Co. is the one of the leading supplier and Stockist of Inconel Alloy Fittings that are manufactured by using supreme quality raw materials located in Mumbai, India.It is an approved manufacturer of high nickel based special Inconel alloy 600/601/625/718 pipe fittings.
Inconel Alloy Fittings offer excellent resistance to corrosion in seawater, which has led to it being extensively used in marine hardware. Inconel Alloy Fittings is a suitable material for heat exchanger tubing and flowing sea water. Some common applications Inconel Alloy Fittings are used in are aircraft ducting systems, aerospace, jet engine exhaust systems, engine thrust-reverser systems, specialized seawater equipment, chemical process equipment. We also offer custom made products to our valuable products.
Specification for Inconel Alloy 600/601/625/718 Fittings
| Grades | Inconel 600 (UNS No. N06600) 2.4816 Inconel 601 (UNS No. N06601) 2.4851 Inconel 625 (UNS No. N06625) 2.4856 Inconel 718 (UNS No. N07718) 2.4668 |
| Range | 1/2"NB TO 12"NB IN |
| Standard | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Designation | ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44 |
| Types | SEAMLESS / WELDED/ FABRICATED |
| SCH | 10, 20, 40, STD, 60, 80, XS |
Chemical Composition for Inconel Alloy 600 Fittings
| Grade | Ni | Fe | C | Mn | Si | Cu | Cr | S |
|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 72.0 min | 6.0 - 10.0 | 0.15 max | 1.0 max | 0.5 max | 0.5 max | 14.0 - 17.0 | 0.015 max |
Chemical Composition for Inconel Alloy 601 Fittings
| Inconel 601 | Ni | Fe | C | Mn | Si | Cu | Cr | S | Al |
|---|---|---|---|---|---|---|---|---|---|
| 58.0 – 63.0 | Balance | 0.10 max | 1.0 max | 0.5 max | 1.0 max | 21.0 – 25.0 | 0.015 max | 1.0 – 1.7 |
Chemical Composition for Inconel Alloy 625 Fittings
| Grade | Ni | Fe | C | Mn | Si | Cr2 | Mo | Co | Al | Ti | Nb + Ta | P | S |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inconel 625 | 58.0 min | 5.0 max | 0.10 max | 0.50 max | 0.50 max | 20.0-23.0 | 8.0-10.0 | 1.0 max | 0.40 max | 0.40 max | 3.15–4.15 | 0.015 max | 0.015 max |
Chemical Composition for Inconel Alloy 718 Fittings
| Inconel | % | Ni | Cr | Fe | Mo | Nb | Co | C | Mn | Si | S | Cu | Al | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 718 | Min. | 50 | 17 | balance | 2.8 | 4.75 | 0.2 | 0.7 | ||||||
| Max. | 55 | 21 | 3.3 | 5.5 | 1 | 0.08 | 0.35 | 0.35 | 0.01 | 0.3 | 0.8 |
Inconel Alloy Fittings, Inconel Alloy 600 Fittings, Inconel Alloy 601 Fittings, Inconel Alloy 625 Fittings, Inconel Alloy 718 Fittings, Inconel Alloy 600 Buttweld Fittings , Inconel Alloy 601 Forged Fittings, Inconel Alloy 625 Socketweld Fittings, Inconel Alloy 718 Threaded Fittings, Inconel Alloy Fittings supplier, Inconel Alloy Fittings Stockist
Prithvi Steel & Engineering Co. exports Inconel Alloy 600/601/625/718 Fittings to Saudi Arabia, UAE, Bahrain, China, Peru, Nigeria, Jordan, Muscat, Kuwait, Dubai, Thailand (Bangkok), Venezuela, Germany, Canada, Russia, Australia, Vietnam, Kazaksthan, Jiddah, Libya, Yemen, Algeria, Qatar, Oman, Iran, United States Of America, United Kingdom, Australia, South Africa, Mexico, Turkey, France, European Union, New Zealand, Angola, Congo, Kenya, Lebanon, Spain, Indonesia, Malaysia, Lebanon, Iraq, Iran, Egypt, Madagascar, Sri Lanka, Denmark, Poland, Italy, Brazil, Sudan, Singapore And Netherlands.
If you have any enquiries related to Inconel Alloy 600/601/625/718 Fttings kindly get back to us on :-
Telephone :- +91-22-6637 3111 / 6639 4241
Email :- prithvisteel@yahoo.co.in / info@prithvisteelengg.com
