Stainless Steel Fittings Supplier & Stockist in India
Stainless Steel 304 / 304L / 310 / 316 / 316L / 316Ti / 317 / 321 / 347 / 904L / Alloy 20 / ALLOY A286 /SMO 254 Buttweld & Forged Fittings Exporter
ASTM A403, ASME SA403 Stainless Steel S30300 / S30403 / S31000 / S31600 / S31603 / S31635 / S31703 / S32100 / S34700 / N08904 / N08020 / S66286 Threaded & Socketweld Fittings Manufacturer & Trader
Prithvi Steel & Engineering Co. is one of the eminent Supplier and Stockist of Stainless Steel Buttweld & Forged Fittings. We are a leading manufacturer and exporter of stainless steel 304 Buttweld & Forged Fittings, along with this numerous grades available in Stainless Steel Buttweld & Forged Fittings such as 304l, 316, 316l, 316ti, 317, 310, 321, 347, 904l, alloy 20, ALLOY A286 and SMO 254 etc.
We are engaged in manufacturing stainless steel Buttweld & Forged Fittings in different sizes and dimensions. It is made by using supreme quality of raw material as per both national and international standards. Our products are checked with standardized testers during the manufacturing process and each batch is further confirmed as being in agreement with the international thread standard. The main reason being is we have an excellent warehouse and storage facilities for both finished and semi-finished goods. They are made ready as per the urgent requirements of the customers.
Specification for Stainless Steel Fittings
| Grades | 304/304L/310/316/316L/316Ti/317/321/347/904L/Alloy 20/ALLOY A286/SMO 254 |
| Designation | ASTM A403, ASME SA403 |
| Size | Seamless 1/2" to 24" , Welded 1/2" to 24", Two Joint / Two Halve Fittings 6" to 48" |
| Schedules | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS |
| Wall Thickness | Sch. 5S To Sch. XXS |
| Type | Seamless / Welded / Fabricated |
Chemical Composition for Stainless Steel Fittings
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00 - 20.00 | 8.00- 10.50 | - | 0.10 | - |
| 304L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00 - 20.00 | 8.00- 12.00 | - | 0.10 | - |
| 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.50 | 24.00- 26.00 | 19.00 - 22.00 | - | - | - |
| 316 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.00 - 18.00 | 10.00 - 14.00 | 2.00 - 3.00 | 0.10 | - |
| 316L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 16.00 - 18.00 | 10.00 - 14.00 | 2.00 - 3.00 | 0.10 | - |
| 317 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00 - 20.00 | 11.00 - 14.00 | 3.00 - 4.00 | 0.10 | - |
| 317L | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00 - 20.00 | 11.00 - 15.00 | 3.00 - 4.00 | 0.10 | - |
| 321 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.00 - 19.00 | 9.00 - 12.00 | - | 0.10 | Ti5 ( C + N ) Min or 0.70 max |
| 347 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.00 - 19.00 | 9.00 - 13.00 | - | - | Cb= 10x ( C Min ) or 1.00 Max |
| 904L | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.00 - 19.00 | 9.00 - 13.00 | - | - | Cb= 10x ( C Min ) or 1.00 Max |
| Alloy 20 | 0.07 | 2.0 | 0.045 | 0.035 | 1.0 | 19.0-21.0 | 32.00-38.00 | 2.0-3.0 | - | 3.0-4.0 Nb 8xC-1.0max |
| ALLOY A286 /SMO 254 | 0.08 | 0.35 | 0.015 | 0.015 | 0.35 | 17-21 | 50-55 | 2.80-3.30 | - | 1.00 max |
Stainless Steel Fittings, 304 Stainless Steel Fittings, 304L Stainless Steel Fittings, 310 Stainless Steel Fittings, 316 Stainless Steel Fittings, 316L Stainless Steel Fittings, 316Ti Stainless Steel Fittings, 317 Stainless Steel Fittings, 321 Stainless Steel Fittings, 347 Stainless Steel Fittings, 904L Stainless Steel Fittings, alloy 20 Stainless Steel Fittings, ALLOY A286 /SMO 254 Stainless Steel Fittings, Stainless Steel Fittings Supplier, Stainless Steel Fittings Stockist.
Prithvi Steel & Engineering Co. exports Stainless Steel Fittings to Saudi Arabia, UAE, Bahrain, China, Peru, Nigeria, Jordan, Muscat, Kuwait, Dubai, Thailand (Bangkok), Venezuela, Germany, Canada, Russia, Australia, Vietnam, Kazaksthan, Jiddah, Libya, Yemen, Algeria, Qatar, Oman, Iran, United States Of America, United Kingdom, Australia, South Africa, Mexico, Turkey, France, European Union, New Zealand, Angola, Congo, Kenya, Lebanon, Spain, Indonesia, Malaysia, Lebanon, Iraq, Iran, Egypt, Madagascar, Sri Lanka, Denmark, Poland, Italy, Brazil, Sudan, Singapore And Netherlands.
